Interesting radiographs - www.easytrauma.co.uk

Fracture anterior process of Calcaneus

Consider if non resolving sprain

Ossicle normal variant - Os peroneum

Condylar fracture (finger)

Significant injury

DONT be deceived by size of fragment

As for all finger injuries look closely for rotational deformity

Consider ORIF

Fragment best seen on oblique view

Giant cell tumour

Juxta articular, Metaphysis into epiphysis

50% around the knee

Lateral condyle fracture (Elbow)

Dont be deceived by small fragment

This is a significant injury

see Paediatric lateral condyle fractures

Metaphyseal radial fracture

Notice dorsal remodeling

This displaced in cast. Why?

This is why you x ray complete metaphyseal fractures weekly for 3 weeks.

See metaphyseal fractures in paediatric section.

This is complete, ie different from a greenstick fracture

Osteopoikilosis

Rare

Multiple, small, ovoid sclerotic areas, widely distributed

Normally asymptomatic

This patient presented with 3rd metatarsal fracture

Trans scaphoid, perilunar dislocation

Notice the lunate is empty

Capitate is not in the cup

Total hip replacement complications

Wear

Aseptic loosening

Implant failure

Segond fracture

Vertical avulsion fracture proximal lateral tibia

Insertion of the lateral capsular ligament

associated with:

ACL tear

Meniscal tear

Light bulb sign

Posterior dislocation gleno humeral joint

Associated with epileptic seizures and electrocution

Rim sign increased glenohumeral space (normal 6mm)

see axillary view or lateral scapular view

Axillary view

Posterior glenohumeral dislocation

Note impaction fracture annterior surface of head

(reverse hill sachs lesion)

see lightbulb sign on AP view

Stress view

Scapholunate dissociation

Rupture of the scapholunate ligament

" Terry Thomas Sign"
